Dimension ES-2024 Ethernet Switch
5-4 System Status and Port Details
Table 5-2 Status: Port Details
LABEL DESCRIPTION
Port Info
Port NO. This field identifies the Ethernet port described in this screen.
Link This field shows whether the Ethernet connection is down, and the speed/duplex mode.
Status This field shows the training state of the ports. The states are FORWARDING (forwarding),
which means the link is functioning normally or STOP (the port is stopped to break a loop or
duplicate path).
LACP This field shows if LACP is enabled on this port or not.
TxPkts This field shows the number of transmitted frames on this port
RxPkts This field shows the number of received frames on this port
Errors This field shows the number of received errors on this port.
Tx KB/s This field shows the number kilobytes per second transmitted on this port.
Rx KB/s This field shows the number of kilobytes per second received on this port.
Up Time This field shows the total amount of time the connection has been up.
Tx Packet
The following fields display detailed information about frames transmitted.
Octet This field shows the number of good octets (unicast, multicast and broadcast) transmitted.
Unicast This field shows the number of good unicast frames transmitted.
Rx Packet
The following fields display detailed information about frames received.
Octet This field shows the number of good octets received.
64 Byte This field shows the number of frames (including bad frames) received that were 64 octets in
length.
65-127 Byte This field shows the number of frames (including bad frames) received that were between 65
and 127 octets in length.
128-255 Byte This field shows the number of frames (including bad frames) received that were between 128
and 255 octets in length.
256-511 Byte This field shows the number of frames (including bad frames) received that were between 256
and 511 octets in length.
512-1023 Byte This field shows the number of frames (including bad frames) received that were between 512
and 1023 octets in length.
1024-1518 Byte This field shows the number of frames (including bad frames) received that were between 1024
and 1518 octets in length.
