Dimension ES-2024 Ethernet Switch
IEEE 802.1Q Tagged VLAN 27-9
For the TagCtl section of the last column, “T“ is a tagged port, “U” is an untagged port.
Figure 27-14 vlan1q svlan list Command Example
27.8 vlan1q vlan list
Syntax:
sys sw vlan1q vlan list
where
_VID|end_VID>=
Specify either all of the VLAN entries ( all ), a single VLAN ID ( VID ) or a
range of VLAN IDs starting from a certain VID ( start_VID ) or a range of
VLAN Ids ending at a specific VID ( end_VID ).
This command shows the current IEEE 802.1Q Tagged VLAN table or a specific part of it.
An example is shown next.
For the EgressPort section of the last column, “E” is an egress port for this VLAN, “-“ is not an egress port for
this VLAN.
The UntaggedPort section of the last column displays “-“ for a tagged port and “U” for an untagged port.
Figure 27-15 vlan1q svlan list Command Example
27.8.1 vlan1q vlan status
Syntax:
ES-2024> sys sw vlan1q svlan list
802.1Q VLAN Static Entry:
idx. Name VID Active AdCtl / TagCtl
---- ------------ ---- -------- ------------------------
0 1 1 active FFFFFFFFFFFFFFFFFFFFFFFFFFFF
UUUUUUUUUUUUUUUUUUUUUUUUUUUU
1 up1 2000 active -----------------------F----
TTTTTTTTTTTTTTTTTTTTTTTTTTTT
2 up1 2001 active ------------------------F---
TTTTTTTTTTTTTTTTTTTTTTTTUTTT
3 example 3 active -----------------------F----
TTTTTTTTTTTTTTTTTTTTTTTTTTTT
ES-2024>
ES-2024> sys sw vlan1q vlan list all
No. VID ElapsedTime Status EgressPort/UntaggedPort
------ ---- ----------- ------ --------------------------------
1) 1 1:04:56 Static EEEEE|EEEEE|EEEEE|EEEEE|EEEEE|EEE
UUUUU|UUUUU|UUUUU|UUUUU|UUUUU|UUU
2) 3 0:35:13 Static -----|-----|-----|-----|---E-|---
-----|-----|-----|-----|-----|---
3) 2000 0:49:17 Static -----|-----|-----|-----|---E-|---
-----|-----|-----|-----|-----|---
4) 2001 0:41:21 Static -----|-----|-----|-----|----E|---
-----|-----|-----|-----|----U|---
ES-2024>
