Dimension ES-2024 Ethernet Switch
22-4 Cluster Management
Figure 22-4 Example: Uploading Firmware to a Cluster Member Switch
The following table explains some of the FTP parameters.
Table 22-3 FTP Upload to Cluster member Example
FTP PARAMETER DESCRIPTION
User name Press
Password The web configurator password default is 1234.
ls Enter this command to list the name of cluster member switch’s firmware and
configuration file.
350DT3b1.bin The name of the firmware file you want to upload to the cluster member switch.
fw-00-a0-c5-05-02-34 The cluster member switch’s firmware name as seen in the cluster manager switch.
config-00-a0-c5-05-02-34 The cluster member switch’s configuration file name as seen in the cluster manager
switch.
22.3 Configuring Cluster Management
Click Configuration from the Cluster Management screen to display the next screen.
C:\> ftp
User :
Password: 1234 is the default password
230 Logged in
230 Logged in
ftp> ls
200 Port command okay
150 Opening data connection for LIST
--w--w--w- 1 owner group 1399654 Jul 01 12:00 ras
-rw-rw-rw- 1 owner group 262144 Jul 01 12:00 rom-0
--w--w--w- 1 owner group 0 Jul 01 12:00 fw-00-a0-c5-05-02-34
-rw-rw-rw- 1 owner group 0 Jul 01 12:00 config-00-a0-c5-05-02-34
226 File sent OK
ftp: 462 bytes received in 0.01Seconds 30.80Kbytes/sec.
ftp> put 350DT3b1.bin fw-00-a0-c5-05-02-34
ftp> bye
