Dimension ES-2024 Ethernet Switch
Introducing the Web Configurator 4-1
Chapter 4
Introducing the Web Configurator
This section introduces the configuration and functions of the Web Configurator.
4.1 Introduction
The embedded web configurator allows you to manage the switch from anywhere through a standard browser
such as Microsoft Internet Explorer or Netscape Navigator.
Use Internet Explorer 5.5 and later or Netscape Navigator 6 and later versions.
4.2 System Login
Use the following steps to log into the switch.
Step 1. Start your Internet Explorer or Netscape Navigator web browser.
Step 2. Type “http://” and the IP address of the switch (for example, the default is 192.168.1.1) in the Location or
Address field. Press Enter.
Step 3. The login screen appears. The default username is admin and associated default password is 1234. The
date and time display as shown if you have not configured a time server nor manually entered a time and
date in the General Setup screen.
Figure 4-1 Web Configurator: login
Step 4. Click OK to view the first web configurator screen.
4.3 Status Screen
The Status screen is the first web configurator screen you see after you log in. The following figure shows the
navigating components of a web configurator screen.
