Dimension ES-2024 Ethernet Switch
Introducing the Web Configurator 4-3
The following table lists the various web configurator screens within the sub-links.
Table 4-2 Web Configurator Screens Overview
BASIC SETTING ADVANCED APPLICATION ROUTING PROTOCOL MANAGEMENT
System Info
General Setup
Switch Setup
IP Setup
Port Setup
VLAN
VLAN Port Setting
Static VLAN
Static MAC Forwarding
Spanning Tree Protocol
Status
Spanning Tree Protocol
Configuration
Bandwidth Control
Broadcast Storm Control
Mirroring
Link Aggregation
Link Aggregation Control
Protocol Status
Link Aggregation
Configuration
Port Authentication
RADIUS
802.1x
Port Security
Access Control
SNMP
Logins
Service Access Control
Remote Management
Queuing Method
Static Routing Maintenance
Firmware Upgrade
Restore Configuration
Backup Configuration
Load Factory Default
Reboot System
Diagnostic
Cluster Management
Status
Cluster Management
Configuration
MAC Table
ARP Table
The following table summarizes the sub-links in the navigation panel.
Table 4-3 Navigation Panel Sub-link Descriptions
LABEL DESCRIPTION
Basic Setting Screens
System Info This link takes you to a screen that displays general system and hardware monitoring
information.
General Setup This link takes you to a screen where you can configure general identification information
about the switch.
Switch Setup This link takes you to a screen where you can set up global switch parameters such as
VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
