Dimension ES-2024 Ethernet Switch
Link Aggregation 14-3
Figure 14-2 Link Aggregation: Link Aggregation Protocol Status
The following table describes the labels in this screen.
Table 14-1 Link Aggregation: Link Aggregation Protocol Status
LABEL DESCRIPTION
Index This field displays the link aggregation ID to identify a link aggregation group, that is, one
logical link containing multiple ports.
Aggregator ID Refer to Figure 14-1 for more information on this field.
Enabled Ports These are the ports you have configured in the Link Aggregation screen to be in the
link aggregation group.
Synchronized Ports These are the ports that are currently transmitting data as one logical link in this link
aggregation group.
Poll Interval(s) The text box displays how often (in seconds) this screen refreshes. You may change the
refresh interval by typing a new number in the text box and then clicking Set Interval.
Stop Click Stop to halt statistic polling.
