Architecture
A-7 MSP50C605 Preliminary Data
Table A–1. MSP50C605 100-Pin PJM Plastic Package Pinout Description
Description Pin# Description Pin# Description Pin# Description Pin#
NC 1 NC 26 NC 51 NC 76
NC 2 NC 27 NC 52 NC 77
NC 3 NC 28 NC 53 NC 78
NC 4 NC 29 NC 54 NC 79
DACM 5 NC 30 NC 55 NC 80
VCC3 6 VCC 31 NC 56 NC 81
DACP 7 VCC1 32 NC 57 PC7 82
VCC 8 SCAN_OUT 33 NC 58 PC6 83
PF7 9 TEST 34 NC 59 PC5 84
PF6 10 SYNC 35 NC 60 PC4 85
PF5 11 SCNCLK 36 NC 61 PC3 86
PF4 12 SCANIN 37 NC 62 PC2 87
PF3 13 INITZ 38 NC 63 PC1 88
PF2 14 PE7 39 NC 64 PC0 89
PF1 15 PE6 40 NC 65 GND 90
PF0 16 PE5 41 NC 66 VCC2 91
GND 17 PE4 42 NC 67 PD7 92
NC 18 PE3 43 NC 68 PD6 93
NC 19 PE2 44 NC 69 PD5 94
NC 20 PE1 45 NC 70 PD4 95
NC 21 PE0 46 NC 71 PD3 96
NC 22 PLL 47 NC 72 PD2 97
NC 23 X1 48 NC 73 PD1 98
NC 24 X2 49 NC 74 PD0 99
NC 25 GND 50 75 GND3 100
