Terminal Assignments and Signal Descriptions
1-13
Introduction to the MSP50C614
For software development and prototyping, a windowed ceramic 120-pin grid
array packaged P614 is available. The P614’s PGA package is shown in
Figure 1–5 and Table 1–3:
Figure 1–5. 120 Pin Grid Array Package for the Development Device, P614
12 13
10 11
8 9
6 7
N
M
K
L
J
H
4
2 3
F
E
C
B
D
A
1
G
5
N
M
K
L
J
H
F
E
C
B
D
A
G
2 1
4 3
6 5
8 7
10
12 11
13
9
extra pin
(bottom view)
(top view)
MSP50P614
Note:
PGA Package
The PGA package is only available in limited quantities for development pur-
poses.
