Instruction Classification
4-35 Assembly Language Instructions
Table 4–22. Class 4a Instruction Description
C4a Mnemonic Description
0 MOV { adrs}, Rx Store R x register to data memory referred by addressing mode {adrs}. Modify
transfer status.
1 MOV R x, {adrs} Load R x with the value in data memory referred by addressing mode {adrs}.
Modify transfer status.
Table 4–23. Class 4b Instruction Description
C4b Mnemonic Description
0 0 ADDB R x, imm8 Add 8 bit positive constant to R x register. Modify RX status.
0 1 SUBB R x, imm8 Subtract 8 bit positive constant from R x register. Modify RX status.
1 0 MOVB R x, imm8 Load R x with the an 8 bit positive constant. Modify RX status.
1 1 CMPB R x, imm8 Store the status of the subtraction (R x – 8 bit positive constant) into RZF and RCF
bits of the STAT register. R x remains unchanged.
Table 4–24. Class 4c Instruction Description
C4c Mnemonic Description
0 0 ADD R x, imm16 Add 16 bit positive constant to R x register. Modify RX status.
0 1 SUB R x, imm16 Subtract 16 bit positive constant from R x register. Modify RX status.
1 0 MOV R x, imm16 Load R x with the an 16 bit positive constant. Modify RX status.
1 1 CMP R x, imm16 Store the status of the subtraction (R x – 16 bit positive constant) into RZF and RCF
bits of the STAT register. R x remains unchanged.
Table 4–25. Class 4d Instruction Description
C4d Mnemonic Description
0 0 ADD R x, R5 Add R5 to R x register, Modify RX status.
0 1 SUB R x, R5 Subtract R5 from R x register. Modify RX status.
1 0 MOV R x, R5 Load R x with R5. Modify RX status.
1 1 CMP R x, R5 Store the status of the subtraction (R x – R5) into RZF and RCF bits of the STAT
register. R x and R5 remain unchanged.
