Terminal Assignments and Signal Descriptions
1-10
1.6 Terminal Assignments and Signal Descriptions
Table 1–1. Signal and Pad Descriptions for the C614
SIGNAL PAD NUMBER I/O DESCRIPTION
Input/Output Ports
PA0 – PA7 75
→
68 I/O Port A general-purpose I/O (1 Byte)
PB0 – PB7 85
→
78 I/O Port B general-purpose I/O (1 Byte)
PC0 – PC7 8 → 1 I/O Port C general-purpose I/O (1 Byte)
PD0 – PD7 18
→
11 I/O Port D general-purpose I/O (1 Byte)
PE0 – PE7 63
→
56 I/O Port E general-purpose I/O (1 Byte)
PF0 – PF7 31 → 24 I Port F key-scan input (1 Byte)
PG0 – PG7 49
→
42 O Port G dedicated output (2 Bytes)
PG8 – PG15 39 → 32
Pins PD4 and PD5 may be dedicated to the comparator function, if the comparator enable bit is set.
Refer to Section 3.3,
Comparator, for details. (Currently not supported)
Scan Port Control Signals
SCANIN 54 I Scan port data input
SCANOUT 50 O Scan port data output
SCANCLK 53 I Scan port clock
SYNC 52 I Scan port synchronization
TEST
PGMPULSE 51 I C614 : test modes
P614 : programming pulse
The scan port pins must be bonded out on any C614 production board.
Consult the “Important Note regarding Scan Port Bond Out”, Section 7.1.1,
Scan Port Bond Out.
Oscillator Reference Signals
OSCIN 65 I Resistor/crystal reference in
OSCOUT 66 O Resistor/crystal reference out
PLL 67 O Phase-lock-loop filter
DAC Sound Output
DACP 22 O Digital-to-analog output 1 (+)
DACM 20 O Digital-to-analog output 2 (–)
Initialization
RESET 55 I Initialization
Power Signals
VSS 9, 19†, 40, 64, 76 Ground
VDD 10, 21†, 23, 41, 77 Processor power (+)
† Pads VSS (19) and VDD (21) service the DAC circuitry. Their pins tend to sustain a higher current draw. A dedicated decoupling
capacitor across these pins is therefore required. Refer to Section 6.1, Application Circuits, for details.
