5 andb bitwise and byte – Texas Instruments MSP50C614 User Manual
Page 174

Individual Instruction Descriptions
4-82
4.14.5 ANDB
Bitwise AND Byte
Syntax
[label]
name
dest, src
Clock,
clk
Word,
w
With RPT,
clk
Class
ANDB
A
n, imm8
1
1
N/R
2a
Execution
dest
⇐
dest AND src byte
PC
⇐
PC + 1
Flags Affected
OF, SF, ZF, CF are set accordingly
Opcode
Instructions
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
ANDB A
n, imm8
1
0
1
0
1
0
1
A
n
imm8
Description
Bitwise AND
src byte and byte stored in dest register and store result in dest register.
See Also
AND, ANDS, OR, ORB, ORS, XOR, XORB, XORS
Example 4.14.5.1
ANDB A2, 0x45
AND immediate value 0x45 to A2 (byte mode). Store result in A2. Upper 8 bits of A2 will be ANDed with
zeros.
