Individual Instruction Descriptions
4-114
4.14.28 MOV Move Data Word From Source to Destination
Syntax
[label] name dest, src, [, next A] Clock, clk Word, w With RPT, clk Class
MOV { adrs}, An[~] [, next A] Table 4–46 Table 4–46 1a
MOV A n[~], {adrs} [, next A] Table 4–46 Table 4–46 1a
MOV { adrs}, *An Table 4–46 Table 4–46 1b
MOV A n[~], imm16 [, next A] 2 2 N/R 2b
MOV MR, imm16 [, next A] 2 2 N/R 2b
MOV A n, An~ [, next A] 1 1 n
R
+3 3
MOV A n[~], PH [, next A] 1 1 n
R
+3 3
MOV SV, A n[~] [, next A] 1 1 n
R
+3 3
MOV PH, A n[~] [, next A] 1 1 n
R
+3 3
MOV A n[~], *An[~] [, next A] 1 1 n
R
+3 3
MOV MR, A n[~] [, next A] 1 1 n
R
+3 3
MOV { adrs}, Rx Table 4–46 Table 4–46 4a
MOV R x, {adrs} Table 4–46 Table 4–46 4a
MOV R x, imm16 2 2 N/R 4c
MOV R x, R5 1 1 n
R
+3 4d
MOV SV, { adrs}
4
1 1 n
R
+3 5
MOV PH, { adrs} Table 4–46 Table 4–46 5
MOV MR, { adrs} Table 4–46 Table 4–46 5
MOV AP n, {adrs} Table 4–46 Table 4–46 5
MOV STAT, { adrs} Table 4–46 Table 4–46 5
MOV TOS, { adrs} Table 4–46 Table 4–46 5
MOV { adrs}, PH Table 4–46 Table 4–46 5
MOV { adrs}, MR Table 4–46 Table 4–46 5
MOV { adrs}, STAT Table 4–46 Table 4–46 5
MOV { adrs}, STR Table 4–46 Table 4–46 5
MOV { adrs}, DP Table 4–46 Table 4–46 5
MOV { adrs}, SV Table 4–46 Table 4–46 5
MOV { adrs}, APn Table 4–46 Table 4–46 5
MOV { adrs}, TOS Table 4–46 Table 4–46 5
MOV STR, { adrs}
8
Table 4–46 Table 4–46 5
MOV { flagadrs}, TFn 1 1 n
R
+3 8a
MOV TF n, {flagadrs} 1 1 n
R
+3 8a
