2
Getting Set Up
2-6
Phaser 380 Color Printer
Touring the printer
Use the following illustration to familiarize yourself with the printer.
1.
Front-cover release
2.
Front-panel menu display and buttons
3.
Exit cover
4.
Exit-cover release button
5.
Ink-loading bins (under top cover)
6.
Top-cover release
7.
On/Off switch and access to I/O ports
8.
Transit restraint lock
9.
Media tray
10.
Front cover
11.
Maintenance tray (consumable item)
9662-03
2
1
4
11
6
5
7
8
9
3
10
