7 Using the Front Panel
7-2 Phaser 380 Color Printer
Front panel buttons
1. The
Exit
button allows you to perform these menu functions:
■
Back up a level in the menu without making a selection.
■
Exit the menu.
2. Button 2, labeled
Info
, lets you cycle through information such as
the printerÕs name, print server name, and the printerÕs IP
address. Pressing
Info
during a print job displays the job name
and job source. When you enter the front panel menu by pressing
Menu
, Button 2 has this function:
■ <----
Scroll backward through the available selections.
3. Button 3, labeled
Clean
during normal operation, lets you access
the cleaning menus. When you enter the front panel menu by
pressing
Menu
, Button 3 changes meaning as you select
sub-menus:
■ ---->
Scroll forward through the available selections.
■ Cancel
Cancel a print job or selection.
■ Confirm
ConÞrm an address change (IP, Broadcast, Gateway).
4. Button 4, labeled
Menu
during normal operation, lets you enter the
front panel menu. After entering the menu, Button 4 changes
meaning as you select submenus:
■ Menu
Provides access to submenus.
■ Print
Executes the selected print.
■ Test
Performs a test print or paper feed operation.
■ OK
Accepts the selected value.
9662-53
Exit
1 2 3 4
