Specifications
System Information
Processor Intel PXA263 CPU at 400MHz
Memory - ROM : 96 MB
- RAM : 128 MB
Operating System Windows Mobile TM software
Display
LCD Type 3.5" transflective TFT-LCD
with back-light LEDs,
touch-sensitive screen
Resolution 240 x 320 at 65,536 colors
GSM/GPRS (Quad-band) Module
GSM 850 824-849, 869-894 MHz
GSM 900 880 ~ 915, 925 ~960 MHz
GSM1800 1710 ~ 1785, 1805 ~ 1880 MHz
GSM1900 1850 ~ 1910, 1930 ~ 1990 MHz
Internal antenna Yes
Camera Module
Type Color CMOS camera module with
reflecting Mirror
Resolution VGA 480 x 640 with JPEG encoder
Camcorder QCIF, Min 15 fps (in live mode),
Max. 15 seconds per clip
Physical
Dimensions 71.6 mm (w) x 125 mm (h) x 18.7 mm (l)
Weight 190g
Expansion Slots
SDIO/MMC Yes
supports
Controls and Lights
Navigation 5-way navigation pad
Buttons - 8 program buttons : Calendar,
Contacts, Camera, VoiceDial,
Star, Inbox, Internet Explorer, OK.
- 2 phone function : Call, End
- Volume control button (Up/Down)
- Power on/off
- Reset button
LED Lights 1 - Event notification
(on the right) - Charge status
- GSM/GPRS signals
LED Lights 2 - Bluetooth system notification
(on the left) - WiFi system notification
Audio
Audio controller AGC
Microphone/ Built-in
Speaker
Headphone
WAV/WMA/AMR/MAR-WB/AAC/
AAC+/MP3 stereo
Connection
Infrared SIR
I/O port 22-pin individual port for signals
(for USB, Serial, and power)
Audio Stereo headphone jack (2.5Ø)
Bluetooth 1.1 compliant, power class 2
WiFi IEEE 802.11b compliant
Power Supply
Battery 1490mAh (typical) Lithium Polymer
removable, rechargeable battery
AC adapter AC input/Frequency :100-140 VAC,
50-60 Hz, Rated Output: 5 VDC, 2A
