RESET when the console is in the pause
mode.
If you complete the whole profile, the
console gives a signal tune and the
displayed value starts blinking after the goal
has been reached. Reset the display by
first pressing START/STOP and thereafter
RESET.
RECOVERY – MEASURING
THE RECOVERY PULSE
Measure your recovery pulse rate at the end
of the workout.
1.
To start the measuring of the recovery
pulse rate, press RECOVERY. The display
also shows the word ”Recovery”.
2.
The measuring starts automatically and
takes two minutes.
3.
Upon completion of the measurement,
the display shows the recovery rate as
a percentage. The smaller the rate, the
fitter you are. Please note that your results
are in a relation to the pulse level in the
beginning of the measurement, and that
your results are personal and cannot directly
be compared with any other person’s
results. In order to improve the reliability of
recovery pulse measurement, always try to
standardize the measurement situation as
accurately as possible; start measuring at
the same heart rate level as precisely as
possible.
4.
To switch back to the main display by
pressing RESET. The console will also
automatically switch to the main display
one minute after the completion of the
measurement.
TRANSPORT AND STORAGE
Move the device according to the following
instruction, because lifting the cycle
incorrectly may strain your back or cause
other risk of accidents:
Stand behind the device and grip the
rail with one hand and the seat with the
other. Tilt the device so that is rests on the
transportation wheels. Move the device by
wheeling it on transportation wheels. Lower
the device onto floor while holding on to
the rail and the seat,all the time remaining
behind the device.
Transport the equipment with caution over
uneven surfaces, for example over a step.
The equipment should never be transported
upstairs using the wheels over the steps,
instead it must be carried. We recommend
that you use a protective base when
transporting the equipment.
To prevent malfunctioning of the cycle, store
in a dry place with as little temperature
variation as possible, protected from dust.
R60 rowing machine may be lifted to an
upright space-saving storage position as
follows:
1.
Loosen the locking pin under the front
frame, press the front frame downward
slightly and pull the locking pin upward.
2.
Open the latch on the left hand side by
pressing the tab to the side. Lift the front
frame up at the same time.
3.
Lower the front frame carefully in between
the rails and lock it with the retainer in the
front end of the seat. Ensure that the front
frame is locked.
4.
Grasp the cross bar at the back of the
rowing machine and lift the device to an
upright position so that it is supported by the
front end support legs.
Store the rowing machine in the storage
position against a wall in such a way that
the front frame cannot fall on anyone by
accident.
