1 233 4072 User interface 1
2 423 2040 Membrane 1
3 693 2005 Monitor holder 1
- KA 35x12 WN-1411 Screw 1
4 173 2039 Foot rest cover 1
- M5x14 DIN 7500 Screw 2
5 363 2007 Foot rest, EUR 2
- 363 2008 Foot rest, USA 2
6 533 2036 Plug 2
- M5x12 DIN 7985 Screw 2
7 453 2002 Cover 1
9 173 2030 Sleeve 2
- M10x65 DIN 912 Hex socket cap screw 2
- M10 DIN 125 Washer 2
- M10 DIN 934 Nut 2
10 643 2010 Locking lever 1
- M5x14 DIN 7500 Screw 2
11 103 2029 Frame 1
12 533 2030 Pulley 2
13 523 2024 Sleeve 2
14 523 2022 Bearing 4
- M8x20 ISO 7380 Hex socket cap screw 4
15 173 2027 Pulley cover 1
- M5x12 DIN 7985 Screw 1
- M6x16 DIN 912 Hex socket cap screw 1
16 443 2011 Rope 1
17 213 2010 Draw bar 1
18 213 2003 Handle grip 2
19 173 2031 Pulley 1
21 693 2002 Pulley bracket 1
- M6 DIN 125 Washer 1
- M6 DIN 985 Nylon nut 1
22 503 2018 Foot strap bracket 1
- M6x35 DIN 912 Hex socket cap screw 2
23 443 2012 Foot strap 1
24 153 2012 Seat roller frame 1
25 72 8012 602 Sleeve 4
26 533 2029 Wheel 4
- M8x35 ISO 7380 Hex. socket cap screw 4
27 153 2014 Seat 1
- M6 DIN 125 Washer 4
- M6x14 ISO 7380 Hex socket cap screw 4
28 103 2024 Main frame 1
29 173 2023 Frame cover, RH 1
- 173 2024 Frame cover, LH 1
- KA 35x12 WN 1411 Screw 8
30 533 1029 Wheel 2
31 673 500 88 Retainer 2
32 503 2016 Rear bracket, LH 1
- 503 2017 Rear bracket, RH 1
- M5x14 DIN 7500 Screw 6
33 173 2025 Rear support cover 2
- M5x12 DIN 7985 Screw 4
34 533 2033 Foot plug 8
- M5x16 DIN 7500 M Countersunk head screw 8
35 433 2021 Case cover 1
- M5x12 DIN 7985 Screw 2
- KA 35x12 WN-1411 Screw 4
36 173 2040 Frame under plate 1
- M5x12 DIN 966 Countersunk head screw 4
37 433 2022 Under plate 1
- M5x12 DIN 966 Countersunk head screw 2
38 373 2011 Brake slacker 1
- M8x80 DIN 603 Lock screw 1
- M8 DIN 985 Nylock nut 1
39 643 2008 Spring 1
40 643 2005 Spring 1
41 533 2032 Adjustment wheel 1
43 173 2032 Spring case (incl. 44 - 48) 1
44 523 1010 Bearing 1
45 333 2002 Spring hub 1
46 643 2006 Spring 1
47 683 2003 Damper 1
48 173 2033 Spring case cover 1
- KA 35x12 WN-1411 Screw 2
- M5x30 DIN 912 Hex socket cap screw 6
49 343 2010 Axle 1
50 303 2007 Flywheel (incl. 51, 52) 1
51 403 1026 Magnet 1
52 523 1010C3 Bearing 1
- 15 DIN 471 Retainer 1
53 173 2034 Belt wheel 2
- 3x30 DIN 7 Cotter-pin 1
54 523 2121 Bearing house 1
- M6x12 DIN 603 Lock screw 2
- M6 DIN 985 Nylock nut 2
55 503 2020 Sensor bracket 1
56 403 2040 Speed sensor 1
- 3,5x13 DIN 7504-K Screw 2
57 693 2003 Spline 1
58 423 9041 Label set 1
59 403 2029 Servo motor 1
- M5x12 DIN 7985 Screw 4
- M5 DIN 985 Nylock nut 1
60 373 2010 Locking lever 1
61 533 1062 Knob 1
62 643 2009 Spring 1
63 683 2002 Bumper 2
64 643 2007 Locking lever 1
- M6x14 ISO 7380 Hex socket cap screw 2
65 403 2035 DC-wire 1
66 403 2036 Remote control card 1
67 173 2041 Remote control cover
(incl. 68) 1
- KB 30x8 WN-1412 Screw 5
- KB 22x7 WN-1412 Screw 1
68 403 2044 Membrane + 1
68 403 2045 Membrane -
69 683 2004 Bumper 1
70 4037020EU Transformer EUR 1
- 4037020GB Transformer GB 1
- 4037020USA Transformer USA 1
- 4031117AUS Transformer AUS 1
- 453 203 Heart rate belt 1
- 583 4055 Owner’s manual 1
- Warranty booklet 1
