310
In This Chapter
V1 Model................................................................................................310
E1 Model................................................................................................311
V1 Model
V1 General Specifications
Form Factor 1U
Dimensions (DxWxH) 24.21”x 19.09” x 1.75” 615 mm x 485 mm x 44
mm
Weight 23.80lb (10.80kg)
Power Single Supply (1 x 300 watt)
Operating Temperature 10° - 35° (50°- 95°)
Mean Time Between
Failure
(MTBF) 36,354 hours
KVM Admin Port (DB15 + PS2 or USB Keyboard/Mouse)
Serial Admin Port DB9
Console Port (2) USB 2.0 Ports
V1 Environmental Requirements
Operating
Humidity 8% - 90% RH
Altitude Operate properly at any altitude between
0 to 10,000 feet, storage 40,000 feet
(Estimated)
Vibration 5-55-5 HZ, 0.38 mm, 1 minutes per cycle;
30 minutes for each axis(X,Y,Z)
Shock N/A
Non-Operating
Temperature -40° - +60° (-40°-140°)
Appendix A Specifications for V1 and E1
