Attendant consoles Page 65 of 504
Telephones and Consoles Description, Installation, and Operation
The Directory Number (DN) designation window on the attendant console is
located above the keypad.
Follow the steps in Procedure 11 to designate keys on an M2250 attendant
console.
Procedure 11
Designating keys on an M2250 attendant console
1 Remove the cap from each key requiring a designation by gently pulling
upward on the cap.
2 Remove the appropriate designation from the sheet of designations.
3 Place the designation in the cap, place the cap over the corresponding
key, and gently press down. Repeat this procedure for all keys requiring
a designation.
4 Insert a paper clip in the hole at the left or right end of the DN designation
window. Pry the window open.
5 Insert the number tag, and replace the designation window.
End of Procedure
The following figures show the typical key designations for the M2250
attendant console:
• Figure 14 on page 66 shows the key designations for the M2250
attendant console in Shift mode.
• Figure 15 on page 67 and Figure 16 on page 68 show the M2250
attendant console in Unshift mode.
