Page 318 of 504 Analog (500/2500-type) telephones
553-3001-367 Standard 3.00 August 2005
Table 48
500/2500 line card pair-terminations for IPE module connectors C, G, M, T
Pair Pins Pair color
I/O panel connectors Unit
C G M T 16/card
1T/1R 26/1 W-BL/BL-W slot 2 slot 6 slot 10 slot 14 8
2T/2R 27/2 W-O/O-W 9
3T/3R 28/3 W-G/G-W 10
4T/4R 29/4 W-BR/BR-W 11
5T/5R 30/5 W-S/S-W 12
6T/6R 31/6 R-BL/BL-R 13
7T/7R 32/7 R-O/O-R 14
8T/8R 33/8 R-G/G-R 15
9T/9R 34/9 R-BR/BR-R slot 2 slot 6 slot 11 slot 15 0
10T/10R 35/10 R-S/S-R 1
11T/11R 36/11 BK-BL/BL-BK 2
12T/12R 37/12 BK-O/O-BK 3
13T/13R 38/13 BK-G/G-BK 4
14T/14R 39/14 BK-BR/BR-BK 5
15T/15R 40/15 BK-S/S-BK 6
16T/16R 41/16 Y-BL/BL-Y 7
17T/17R 42/17 Y-O/O-Y 8
18T/18R 43/18 Y-G/G-Y 9
19T/19R 44/19 Y-BR/BR-Y 10
20T/20R 45/20 Y-S/S-Y 11
21T/21R 46/21 V-BL/BL-V 12
22T/22R 47/22 V-O/O-V 13
23T/23R 48/23 V-G/G-V 14
24T/24R 49/24 V-BR/BR-V 15
25T/25R 50/25 V-S/S-V Spare
