Appendix A: Meridian Modular Telephones Page 347 of 504
Telephones and Consoles Description, Installation, and Operation
When installing an MCA or MPDA to NTZK or NT2K phone sets with a date
code prior to January 1998, a Power Option board is required, along with an
additional power source. When installing an MCA in an NT9K phone set or
an NT2K with date code of January 1998, install only the MCA (an additional
Power Option board and Jumper board are not required).
The Power Supply Board connects to the telephone through a 14 pin bottom
entry connector.
The Power Supply Board comes factory installed with any configuration of
the M2216ACD-2. The M2006 and M2008 require the Power Supply Board
with the addition of any option. The M2616 requires the Power Supply Board
with any option except the Display Module.
Refer to Figure 55 on page 347 and Figure 56 on page 348 for power supply
board requirements.
Table 55
NT2K model Power requirements, Meridian Modular Telephone sets
Telephone type Loop power
Additional power
(Power Supply Board and
Transformer)
M2006 Basic configuration Any option(s)* (MPDA, External
Alerter Interface, MCA)
M2008/M2008HF Basic and Display configurations MPDA, External Alerter Interface
M2616 Basic, Display, and Handsfree
configurations and Key Expansion
Module(s) MCA, MPDA, External Alerter
Interface, MCA
M2216ACD Basic configurations (with Display)
Key Expansion Module(s).
MPDA, Key Expansion Module,
External Alerter Interface, MCA
*No display can be added to the M2006 set.
