Page 452 of 504 Appendix D: M2317 telephone
553-3001-367 Standard 3.00 August 2005
Software requirements
All information related to the programmable keys must be downloaded into
the M2317 RAM memory through the DLC or ISDLC. Downloading to the
telephone is performed when the system is loaded or when a telephone is
enabled.
Soft keys are automatically defined for the telephone based on Class of
Service (CLS), database, or package restrictions. Soft keys work only in
conjunction with the LCD display screen.
Table 75 lists the data features supported by the M2317 firmware.
Table 75
M2317 data features
Data features M2317 DTE Keyboard
Ring Again X X
Speed Call X X
System Speed Call X X
Display X
Call Forward X
Call Transfer (Note 1) X
Autodial X X
Last Number Redial X
Save Number X
Redial Saved Number X
Note 1: Manual modem pooling using keyboard dialing requires only call
transfer to be defined.
Note 2: The Data DN must always be assigned to feature key 10.
