Page 36 of 504 Attendant consoles
553-3001-367 Standard 3.00 August 2005
Figure 2
Volume slider position
3 Place the attendant console facedown on a properly prepared work
surface, taking care to avoid scratching or damaging the top cover or
display. Remove the adjustable stand, if required.
The stand is secured with four screws. Remove the stand as a complete
assembly, and set aside.
4 Remove the 12 fastening screws in the base of the attendant console that
secure the top cover to the console base. See Figure 3 on
page 37 .
Holding the console base and cover firmly, turn it over so that the top
cover is on, facing up.
Move Volume Slider
to left-most position
553-AAA0626
