Page 58 of 504 Attendant consoles
553-3001-367 Standard 3.00 August 2005
3 Run the wire or cable between the telephone location and nearest
cross-connect point (if not previously run).
4 Connect the cable or wire to the telephone connecting block.
5 Designate the telephone connecting block.
Figure 12
Zone cabling and conduit assignment
6 Cross-connect the pairs at intermediate cross-connect points (if required)
and terminate at the cross-connect terminal.
Zone Zone Zone Zone
Zone Conduit
Each Zone is
approximately
600-800 feet
1.2
1.1
1
2.1
2.2
2
3 4
5 6
7
8
9
10
11
12
13 14 15 16
17
18
19 20
Apparatus
Closet
553-AAA0579
Satellite
Closet
