Appendix C: Meridian Modular Telephones add-on modules installation
553-3001-367 Standard 3.00 August 2005
12 Insert the fillerplate screws in the Display Module screw holes
13 Tighten the fillerplate screws.
Note: Place the label supplied with the display on the outside of the
bottom cover of the telephone. This allows proper identification and
tracking of the option level of the set.
Figure 78
Positioning the display module
. . . . . . . .
. . . . . . . .
553-AAA0644
