Appendix C: Meridian Modular Telephones add-on modules installation
553-3001-367 Standard 3.00 August 2005
3
Disconnect and remove all cords (including the handset cord) from the
telephone.
4
Place the telephone, face-down, on a padded level surface.
5
Using a #1 Phillips screw driver, remove both screws and separate the
footstand from the phone base.
6
If using the NT9K ATA ready set or the NT2K with date code of April 24,
1998 or later:
•
Remove and retain the footstand (this footstand will be reattached
back onto the set base after ATA installation is complete.
•
Skip to the ATA Installation Procedure 13 on
.
7
If using the NT2K or the NTZK phone set, remove and discard the
footstand. Use the redesigned footstand required for the installation of the
ATA.
8
If an MCA or MPDA installed is installed, unplug it from the data line jack
in the phone base.
9
Remove the back covering of the phone base by removing the four
screws.
KEY
Prime Directory Number Key, SCR, SCN, MCR or MCN and xxx.
-Key
xx SCR yyyy
Single Call Ringing
xx SCN yyyy
Single Call Non Ringing Data Mode Key, where xx = key number
and yyy = Data Directory Number.
Table 66:
Flexible Voice and Data feature configuration (Part 2 of 2)
Prompt
Response
Description
