M3900 installation and configuration Page 197 of 504
Telephones and Consoles Description, Installation, and Operation
Table 36 shows prompts and responses when configuring the ATA.
Installing Personal Directory PC Utility software
The Personal Directory PC Utility provides a faster, easier way to create or
modify a personal directory. You can enter names and numbers into a
Personal Directory file on your Personal Computer (PC). You can download
the PC file directly to the M3904 or M3905 telephone. You can upload a
directory from the M3904 to a PC to modify the M3904 directory.
Use Procedure 35 to install the Personal Directory PC Utility software.
Procedure 35
Installing the Personal Directory PC Utility
software
1 Close all open applications before installing the Personal Directory PC
Utility.
2 Insert the Personal Directory PC Utility disk into your floppy disk drive.
3 Click on Start.
4 Select Run.
Table 36
ATA configuration
Prompt Response Description
REQ NEW
CHG
Input new data
Change current data.
CLS aaaa Class of Service options, where aaaa:
= (FLXD) - Flexible voice/data denied
= FLXA - Flexible voice/data allowed, required if ATA
equipped.
= (VCE) - Voice terminal, required if ATA equipped.
= DTA - Data terminal.
Note: If ATA is installed, CLS must be FLXA, VCE.
KEY 0 SCR xxxx Single Call Ringing, where xxxx = the DN for ATA
