Appendix D: M2317 telephone Page 449 of 504
Telephones and Consoles Description, Installation, and Operation
Not all the features listed in Table 74 are provided for each customer. Check
only those features that are enabled in accordance with the work order.
The - - ->> symbol display is associated with the Call Party Name Display
(CPND) feature. CPND must be enabled before it can be accessed.
Table 74
M2317 states and associated soft keys (Part 1 of 3)
Screen state State Softkey display
Idle On-hook, voice or data
Dialtone Ready to transmit dialed digits
(voice)
Intercom dialtone Ready to transmit dialed digits for
an intercom call (voice) PICKUP
Dialing Transmitting dialed digits no soft keys shown
Private Line dialing Transmitting dialed digits on a
private line (voice) SAVED#, LAST#
Busy Called party off-hook (voice) RINGAGN, SAVE#
Reorder Called party is unavailable (voice) no soft keys shown
Ringback Called party is ringing (voice) SAVE#
ERWT call back Initial set of ESN routes not
available. Set gets Expensive
Route Warning Tone (voice). RINGAGN, SAVE#
Saved#, LAST#, CANCL ,
--->, more..., HELD#,
FORWARD, CHECK ,
TIMER, more..., RLSDATA,
DATA, SPEED
Saved#, LAST#, CALL ,
SPEED#, more..., MESSAGE,
PICKUP, ACCOUNT, more...
