Figure 7 on, Figure 7) – Nortel Networks M3110 User Manual
Page 41
Attendant consoles
Page 41 of 504
Telephones and Consoles
Description, Installation, and Operation
22 Define the Busy Lamp Field in the system database. Refer to Features
and Services (553-3001-306).
23 Test the Busy Lamp Field features using M1250/M2250 Attendant
Console User Guide.
Figure 7
Positioning the top cover and the BLF/CGM
Rotate Back
BLF/CGM
Top Cover
Base
Slide Back
and Down
553-AAA0632
