Attendant consoles
Page 37 of 504
Telephones and Consoles
Description, Installation, and Operation
Figure 3
Removing the fastening screws
5
Raise and hold the top cover to remove the single cable connector only.
The alerter cable does not need to be removed. See Figure 4 on
6
Remove the top cover, and place it upside down to the left of the attendant
console.
Do Not Remove
These Screws
Do Not Remove
These Screws
Remove These
12 Screws
Polystyrene
Foam Sheet
553-AAA0627
