M2016S Secure Set Page 119 of 504
Telephones and Consoles Description, Installation, and Operation
Designate the telephone
Before designating the M2016S telephone, check the work order for the
features enabled and key designations. Designate each key by placing its
feature name (from the designation sheet) in the key cap that fits on the key.
Follow the steps in Procedure 26 to designate the M2016S telephone.
Procedure 26
Designating the M2016S telephone
1 Remove the cap from each key requiring a designation.
2 Place the designation in the cap, place the cap over the corresponding
key, and gently press down. Repeat for all keys requiring designations.
3 Insert a paper clip into the hole at the left or right end of the designation
window.
4 Gently pry the window toward the center and remove, and insert the
number tag.
5 Replace the designation window.
End of Procedure
Cross-connect the telephone
Be sure to connect the telephones as shown in Figure 24 on page 121 .
Follow the steps in Procedure 27 to cross-connect the telephones.
Procedure 27
Cross-connecting the telephones
1 Locate the telephone terminations at the cross-connect terminal.
Telephone terminations are located on the vertical side of the frame when
frame-mounted blocks are used and in the blue field when wall-mounted
blocks are used.
2 Connect Z-type cross-connecting wire to the leads of the telephone. See
Table 16 on
page 120 and Table 17 on page 121 .
3 Locate the line circuit card (TN) terminations.
