Analog (500/2500-type) telephones
553-3001-367 Standard 3.00 August 2005
2
Connect Z-type cross-connecting wire to the leads of the telephone. See
Table 49 on
3
Locate the line circuit card (TN) terminations.
Line circuit card (TN) terminations are located on the horizontal side of the
distributing frame when frame-mounted blocks are used and in the white
field when wall-mounted blocks are used.
4
Run and connect the other end of the cross-connecting wire to the
assigned TN terminal block.
End of Procedure
