Configuration Worksheet for Bridge Mode (1 of 2)
Date:________________________________________________
Location:_____________________________________________
Local Phone Number: (
j
)___________________________
Device:______________________________________________
Local Address:_________________________________________
j
DBM Installed
Serial Number:_________________________________________
Tributary Network Address:_______________________________
j
SNA Diagnostic Interface (LPDA-2) Enabled
MUX Setup
Configuration
Options
Value
MUX Funct:
(CBrdg or EBrdg)
TDM, MCMP
a
, CBrdg, EBrdg, None
Bridge Rate
=DSU
z
, 64, 56, 28.8, 24.0, 19.2, 16.8,
14.4, 12.0, 9.6, 4.8, 2.4
Brdg Timing
}}}
Int, Auto, Prt1, Prt2, Prt3, Prt4, Prt5,
Prt6
Share DevA:
Enab
Lowest Port #
DCE, 2, 3, 4, 5
#Ports in Gp:
2, 3, 4, 5, 6
Port Cntrl:
Host, DSD
Share DevB:
Disab
a
MCMP option only
z
Does not appear for EBrdg
}}}
Ports 3–6 not available for 2-port Flex MUX models
:
Available for MCMP/Flex and TDM/Flex with DSU firmware
version 6.33 or greater
A
Configuration options that do not appear when Full mode is
disabled using Menu from the configuration branch.
Prt4
Configuration
Options
Value
RTS Cntrl
FrcOn, DTE
TxCarrSel
A
Const, Cntrl
RxCarrSel
A
Const, Cntrl, Mark
PCC Buffer
Enab, Disab
Elast Stor
A
Enab, Disab
RTS/CTS Del
A
0–1040 ms
(8 ms increments)
DTR Alarm
A
Enab, Disab
AntiStream
A
Disab, 1–100 sec (async term = 0–100)
DSR FrcOn
A
Enab, Disab
DSR on Tst
A
Enab, Disab
Extend Chan
A
Yes, No
Upstrm Port
}}}
A
Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
:
EIA232, V.35
Prt2
Configuration
Options
Value
RTS Cntrl
FrcOn, DTE
TxCarrSel
A
Const, Cntrl
RxCarrSel
A
Const, Cntrl, Mark
PCC Buffer
Enab, Disab
Elast Stor
A
Enab, Disab
RTS/CTS Del
A
0–1040 ms
(8 ms increments)
DTR Alarm
A
Enab, Disab
AntiStream
A
Disab, 1–100 sec
(async term = 0–100)
DSR FrcOn
A
Enab, Disab
DSR on Tst
A
Enab, Disab
Extend Chan
A
Yes, No
Upstrm Port
}}}
A
Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
:
EIA232, V.35
Prt5
Configuration
Options
Value
RTS Cntrl
FrcOn, DTE
TxCarrSel
A
Const, Cntrl
RxCarrSel
A
Const, Cntrl, Mark
PCC Buffer
Enab, Disab
Elast Stor
A
Enab, Disab
RTS/CTS Del
A
0–1040 ms
(8 ms increments)
DTR Alarm
A
Enab, Disab
AntiStream
A
Disab, 1–100 sec
(async term = 0–100)
DSR FrcOn
A
Enab, Disab
DSR on Tst
A
Enab, Disab
Extend Chan
A
Yes, No
Upstrm Port
}}}
A
Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
:
EIA232, V.35
Prt3
Configuration
Options
Value
RTS Cntrl
FrcOn, DTE
TxCarrSel
A
Const, Cntrl
RxCarrSel
A
Const, Cntrl, Mark
PCC Buffer
Enab, Disab
Elast Stor
A
Enab, Disab
RTS/CTS Del
A
0–1040 ms
(8 ms increments)
DTR Alarm
A
Enab, Disab
AntiStream
A
Disab, 1–100 sec
(async term = 0–100)
DSR FrcOn
A
Enab, Disab
DSR on Tst
A
Enab, Disab
Extend Chan
A
Yes, No
Upstrm Port
}}}
A
Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
:
EIA232, V.35
Prt6
Configuration
Options
Value
RTS Cntrl
FrcOn, DTE
TxCarrSel
A
Const, Cntrl
RxCarrSel
A
Const, Cntrl, Mark
PCC Buffer
Enab, Disab
Elast Stor
A
Enab, Disab
RTS/CTS Del
A
0–1040 ms
(8 ms increments)
DTR Alarm
A
Enab, Disab
AntiStream
A
Disab, 1–100 sec
(async term = 0–100)
DSR FrcOn
A
Enab, Disab
DSR on Tst
A
Enab, Disab
Extend Chan
A
Yes, No
Upstrm Port
}}}
A
Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
:
EIA232, V.35
