Paradyne COMSPHERE 3611 - Manual (Page 55)

Configuration Worksheet for MCMP Mode (1 of 3)
Date:________________________________________________ Location:_____________________________________________ Local Phone Number: ( )____________________________
Device:______________________________________________ Local Address:_________________________________________
j
DBM Installed
Serial Number:________________________________________ Tributary Network Address:_______________________________
j
SNA Diagnostic Interface (LPDA-2) Enabled
MUX Setup
Configuration Options
Value
MUX Funct TDM, MCMP, CBrdg, EBrdg, None
Share DevA Enab, Disab
Lowest Port # 1, 2, 3, 4, 5
#Ports in Gp 2, 3, 4, 5, 6
Port Cntrl Host, DSD
Share DevB Enab, Disab
Lowest Port # 1, 2, 3, 4, 5
#Ports in Gp 2, 3, 4, 5, 6
Port Cntrl Host, DSD
P1/2 FEPSh Enab, Disab
P3/4 FEPSh Enab, Disab
P5/6 FEPSh Enab, Disab
MCMP Bckup
H MCMP, TDM
H ISDN and Switched 56 kbps Digital DBMs only
}}} Ports 3–6 are not available for 2-port Flex MUX models.
: Available for MCMP/Flex with DSU firmware version 6.33 or greater
A Configuration options that do not appear when Full mode is disabled
using Menu from the Configuration branch.
Prt3
Configuration Options
Value
Async → Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
: EIA232, V.35
DCE Type Analg, Digtl
Prt1
Configuration Options
Value
Async → Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
: EIA232, V.35
DCE Type Analg, Digtl
Prt4
Configuration Options
Value
Async → Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port : EIA232, V.35
DCE Type Analg, Digtl
Prt2
Configuration Options
Value
Async → Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
: EIA232, V.35
DCE Type Analg, Digtl
Prt5
Configuration Options
Value
Async → Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port
: EIA232, V.35
DCE Type Analg, Digtl
