Data Service Unit Menu
A-5 3610-A2-GB48-50 September 1996
Table A-1
(2 of 3)
Factory Default MUX Configuration Options
MUX Port n
Configuration Options
FacC
Control
FacT
Tributary
FacB
Digital
Bridge
MPTC
Multipoint
Control
MPTT
Multipoint
Tributary
Async–>Sync Disable Disable Disable Disable Disable
AsyncRate =Sync =Sync =Sync =Sync =Sync
AsyncBit/Char 8 8 8 8 8
Stop Bits 1 1 1 1 1
Overspeed 2.50 2.50 2.50 2.50 2.50
RTS Control DTE DTE DTE DTE DTE
TxCarrierSelect Constant Constant Constant Constant Constant
RxCarrierSelect Constant Constant Constant Constant Constant
PCC Buffer Disable Disable Disable Disable Disable
Elastic Store Disable Disable Enable Disable Disable
RTS/CTS Delay 0 0 0 0 0
DTR Alarm Disable Disable Disable Disable Disable
AntiStream Disable Disable Disable Disable Disable
DSR FrcOn Enable Enable Disable Enable Enable
DSR on Test Enable Enable Disable Enable Enable
Extend Channel No No No No No
Upstream Port Port 1 Port 1 Port 1 Port 1 Port 1
DTE Port EIA232 EIA232 EIA232 EIA232 EIA232
DCE Type Analog Analog Analog Analog Analog
DSU Port Speed
Configuration Options
FacC FacT FacB MPTC MPTT
Port 1 9.6 kbps 9.6 kbps 9.6 kbps 9.6 kbps 9.6 kbps
Port 2 Disable Disable 9.6 kbps Disable Disable****
Port 3 — Port 6 Disable Disable 9.6 kbps Disable Disable
Underspeed Disable Disable Disable Disable Disable
**** DSU Port 2 port speed for MPTT defaults to 9.6 kbps when TDM is installed.
