Configuration Worksheet for TDM Mode (2 of 3)
Prt6
Configuration Options
Value
Async
→
Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
Overspeed 1.25, 2.50
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async terminal = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port
}}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port : EIA232, V.35
DCE Type Analg, Digtl
DSU
Configuration
Options
Value
Rate(Kbps) Auto, 64CC, 64L, 56, 38.4, 19.2, 9.6, 4.8, 2.4
TxClkSource
}}} Int, RXC, DDS, Prt1, Prt2, Prt3, Prt4, Prt5,
Prt6
Msg Clamp A Enab, Disab
TxElasStor Enab, Disab
RxElasStor A Enab, Disab
19.2 PowrLvl
D D A +6, 0, –10
64KScrambling A On, Off
64KLatchLpbk A On, Off
NetIntf A AggSw, Forc, Disab
NetI Timing }}} A Int, NetI, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
V.54 Lpbk A Enab, Disab
Diagnostic DSU
Configuration
Options
Value
Diag Type NonD, Disr, Mixed, None
2nd Ch(bps) A 100, 400, 800, 1200, 1600
Disr Type 2500, 2600, 3600s, 3600e, Br56
Diagnostic DBM
Configuration
Options
Value
Diag Type NonD, Disr, Mixed, None
2nd Ch(bps) A 100, 400, 800, 1200, 1600
RemoteDiag A V.54, Enhan, 2500
FBDiagTyp1
} NonD, Disr, Mixed, None
FB 2nd Ch1
} A 100, 400, 800, 1200, 1600
FBDiagTyp2
HH NonD, Disr, Mixed, None
FB 2nd Ch2 HH A 100, 400, 800, 1200, 1600
Diagnostic General
Configuration
Options
Value
Position Cntrl, Trib, G2Trb
LinkConfig Pt-Pt, M-Pt
Resp Period A 1, 2, 10
Trib TimOut A min and sec (5 sec. to 10 min.)
Diag Conn CC, DC
Link Delay A 0s, 1s, 2s, 5s, 10s, 20s, 50s
Network Delay A 0s, 1s, 2s, 5s, 10s, 20s, 50s
Packet Delay A 0s, 1s
,
2s, 5s
M-Pt SymPrt A Enab, Disab
Fast Sel A Enab, Disab
DSU TDM PrtSp
Configuration
Options
Value
Prtn (SS.S)
D }}} 64, 56, 48, 38.4, 32, 28.8, 24.0, 19.2, 18.8,
18.0, 16.8, 14.4, 12.0, 9.6, 9.2, 8.4, 7.2, 4.8,
4.4, 4.0, 2.4, 2.0, 1.2, Disab
Underspeed
}}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM PrtSp
Configuration Options
Value
Prtn (SS.S)
D}}} 64, 56, 48, 38.4, 32, 28.8, 24.0, 19.2, 18.8,
18.0, 16.8, 14.4, 12.0, 9.6, 9.2, 8.4, 7.2, 4.8,
4.4, 4.0, 2.4, 2.0, 1.2, Disab
Underspeed }}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM Fallback1 PrtSp
Configuration Options
Value
Prt n (SS.S)
}D}}} 56, 48, 38.4, 32, 28.8, 24.0, 19.2, 18.8, 18.0,
16.8, 14.4, 12.0, 9.6, 9.2, 8.4, 7.2, 4.8, 4.4,
4.0, 2.4, 2.0, 1.2, Disab
Underspeed }}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM Fallback2 PrtSp
Configuration Options
Value
Prt n (SS.S)
HHD}}} 56, 48, 38.4, 32, 28.8, 24.0, 19.2, 18.8, 18.0,
16.8, 14.4, 12.0, 9.6, 9.2, 8.4, 7.2, 4.8, 4.4,
4.0, 2.4, 2.0, 1.2, Disab
Underspeed
}}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
} ISDN and V.34 DBMs only
}}} Ports 3–6 not available for 2-port Flex MUX models
: Available for TDM/Flex with DSU firmware version 6.33 or
greater
D When the Async → Sync configuration option is enabled
using MUX Port n, the following PrtSp settings will not
appear:
32, 24.0, 18.8, 18.0, 9.2, 8.4, 4.4, 4.0, and 2.0 kbps.
D D 19.2 Power Level defaults to +6 dB when ID App Module
displays XLOOP
HH V.34 Analog DBM only
n = Port number
SS.S = Aggregate rate
A Configuration options that do not appear when Full mode
is disabled using Menu from the Configuration branch.
