Configuration Worksheet for MCMP Mode (2 of 3)
Prt6
Configuration Options
Value
Async
→
Sync Enab, Disab
Async Rate =Sync, 1800, 1200, 600, 300, 150
AsyncBit/Char 6, 7, 8, 9, 10
Stop Bits 1, 2
RTS Cntrl FrcOn, DTE
TxCarrSel A Const, Cntrl
RxCarrSel A Const, Cntrl, Mark
PCC Buffer Enab, Disab
Elast Stor A Enab, Disab
RTS/CTS Del A 0–1040 ms (8 ms increments)
DTR Alarm A Enab, Disab
AntiStream A Disab, 1–100 sec (async term = 0–100)
DSR FrcOn A Enab, Disab
DSR on Tst A Enab, Disab
Extend Chan A Yes, No
Upstrm Port }}} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
DTE Port : EIA232, V.35
DCE Type Analg, Digtl
DSU
Configuration Options
Value
Rate(Kbps) 56
TxClkSource Int, RXC, DDS
Msg Clamp A Enab, Disab
TxElasStor Enab, Disab
RxElasStor A Enab, Disab
19.2 PowrLvl D D A +6, 0, –10
64KScrambling A On, Off
64KLatchLpbk A On, Off
NetIntf A AggSw, Forc, Disab
NetI Timing A Int, NetI
V.54 Lpbk A Enab, Disab
Diagnostic DSU
Configuration Options
Value
Diag Type NonD, Disr, None
2nd Ch(bps) A 100, 400, 800, 1200, 1600
Disr Type 3600s, 3600e, Br56
Diagnostic DBM
Configuration Options
Value
Diag Type NonD, Disr, None
2nd Ch(bps) A 100, 400, 800, 1200, 1600
RemoteDiag A V.54, Enhan, 2500
FB DiagTyp1
} NonD, Disr, Mixed, None
FB 2nd Ch1 } A 100, 400, 800, 1200, 1600
FB DiagTyp2
HH NonD, Disr, Mixed, None
FB 2nd Ch2 HH A 100, 400, 800, 1200, 1600
Diagnostic General
Configuration Options
Value
Position Cntrl, Trib
LinkConfig Pt-Pt, M-Pt
Resp Period A 1, 2, 10
Trib TimOut A min and sec (5 sec. to 10 min.)
Diag Conn CC, DC
Link Delay A 0s, 1s, 2s, 5s, 10s, 20s, 50s
Network Delay A 0s, 1s, 2s, 5s, 10s, 20s, 50s
Packet Delay A 0s, 1s, 2s, 5s
Fast Sel A Enab, Disab
DSU MCMP PrtSp
Configuration Options
Value
Prt n (SS.S) }}} 48, 38.4, 19.2, 16.8, 14.4, 12.0, 9.6, 7.2, 4.8,
2.4, 1.2, Disab
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM PrtSp
Configuration Options
Value
Prt n (SS.S)
}}} D ** 48, 38.4, 32, 28.8, 19.2, 18.0, 16.8, 14.4,
12.0, 9.6, 8.4
, 7.2, 4.8, 4.0, 2.4, 2.0, 1.2,
Disab
Underspeed
}}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM Fallback1 PrtSp
Configuration Options
Value
Prt n (SS.S)
} D }}} 48, 38.4, 32, 28.8, 19.2, 18.0, 16.8, 14.4,
12.0, 9.6, 8.4, 7.2, 4.8, 4.0, 2.4, 2.0, 1.2,
Disab
Underspeed
}}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
DBM Fallback2 PrtSp
Configuration Options
Value
Prtn (SS.S) HH D }}} 48, 38.4, 32, 28.8, 19.2, 18.0, 16.8, 14.4,
12.0, 9.6, 8.4, 7.2, 4.8, 4.0, 2.4, 2.0, 1.2,
Disab
Underspeed }}} Disab, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Prt1 Prt2 Prt3 Prt4 Prt5 Prt6
: Available for MCMP/Flex with DSU firmware version 6.33
or greater
HH V.34 DBM only
} ISDN and V.34 DBMs only
}}} Ports 3–6 are not available for 2-port Flex MUX models.
D When the Async
→
Sync configuration option is enabled
using the MUX Port n branch, the following DBM PrtSp
settings will not appear: 32, 18.0, 8.4, 4.0, and 2.0 kbps
D D 19.2 Power Level defaults to +6 dB when App Module ID
displays XLOOP
n = Port number
SS.S = Aggregate rate
A Configuration options that do not appear when Full mode
is disabled using Menu from the Configuration branch.
