February 2003 2-19
1000-A2-GN22-00 2. CPX-1000 Voice Services Platform Description
Table 2–4. MP Module Controls, Indicators, and Ports
Card Controls, Indicators, and Ports Function
Management
Processor Card
(Front) T64 1 ETHERNET Connects to CP A module’s Ethernet
port
Link (green) Link is established
ACT (Amber) Ethernet circuit is in use
T64 2 ETHERNET Connects to CP B module’s Ethernet
port
LINK (green) Link is established
ACT (Amber) Ethernet circuit is in use
ETHERNET Connects to LAN or PC for access to
network management systems. Port
is only in service when no MP
transition card is present.
COM1 Connects to PC via serial cable for
network management via
HyperTerminal.
RESET Press to restart processor
EXT Hot swap
PWR MP and MP transition cards powered
MP Transition Card
(Rear) Keyboard/Mouse Port Not used
VIDEO Not used
COM 2 Connects to a modem for Paradyne
support only
ETHERNET 2 Not used
ETHERNET 1 Connects to LAN or PC for access to
network management systems.
