D. Specifications

1000-A2-GN22-00

D-6

February 2003

ATM Connection OC-3 Optical

Physical interface

Short-haul, single- or multi-mode, fiber optic (OC-3) cable
Max. span length: 5000 ft

Termination

Standard (SC) or Fusion Coupler (FC) connector plugs

Xmt power

MMF:

−19 to −14 dBm; SMF: −15 to −8 dBm

Rcv power

MMF:

−44.5 dBm to −8.0 dBm; SMF:−34 to −8 dBm

Wave length

1270–1380 nm

Logical interface

UNI

Max. span length

5000 ft.

Ethernet LAN

Physical interface

CAT-5 or equivalent cable for 10Base-T or 100Base-T

Termination

RJ-45 plug

Alarm Output Connection

Wiring requirement

22 AWG

Telco alarm signaling

Form-A solid-state closure Critical, Major, and Minor Alarm
with individual returns

Rated resistive load

20

Ω (typ) @ 50 mA

5

Ω (typ) @ 100 mA

Operating voltage

100 VDC/VAC (350 VDC or peak ac for 100 ms transients)

Continuous load

250 mA dc, 150 mA ac

Minimum load

10

µA at 10 mVDC

Table D–4. CPX-1000 Electronic Specifications (Continued)

Parameter

Specification
