Paradyne Jetstream CPX-1000 User Manual

Page 141

February 2003

B-3

1000-A2-GN22-00

B. Pin Assignments and Indicators

Ethernet LAN
(10Base-T or 100Base-T)

Physical interface:

CAT-5 or equivalent cable

Termination: RJ-45

plug

T-1 PSTN
(Host Class 5 switch)

Physical interface:

DS1 short-haul 4-wire, twisted pair
(ABAM)

Impedance:

100

Ω (nominal)

Max. span length:

655 ft.

Line Build Out:

0–133 ft., 133–266 ft., 399–533 ft.,
533–655 ft.
(factory set per customer order)

Termination: RJ-48C

plug

Signal amplitude:

2.4 to 3.6V (DSX-1)

Rcv Attenuation:

<10dB (DSX-1)

Framing:

ESF (10 ms maximum)

Line coding:

B8ZS

Clock:

T-1/DS-1 Rcv span
(defaults to internal if Rcv fails)

STS-1 PSTN
(Host Class 5 switch)

Physical interface:

DS-3 short-haul coaxial cable

STS-1 module is a 51.84 Mbps full

duplex link between the cPCI bus
in the CPX-1000 and the external
PSTN network.

Impedance: 75

Ω (nominal)

Max. span length:

450 ft. of 734A or equivalent

coaxial cable

Termination:

Dual socket BNC coaxial

connectors

Signal amplitude:

±1.75 volts ±10%

Xmt power:

-2.7 to +4.7 dBm

Transmission rate:

51.84 Mbps full duplex

Line coding:

B3ZS

Table B–1. Connection Requirements and Physical Layer

Specifications (Continued)

Connections

Cables, Connectors, and Specifications
