2. CPX-1000 Voice Services Platform Description

The three Telco alarms and a rack alarm are also routed through a
dry contact relay to the RJ-45 remote alarm connector.

The standard Telco alarm signals and rack alarm are available as an
output to remote alarm equipment (

Table 2–2

).

Table 2–1. Alarm Indicator Status and Description

Alarm Indicator

Status

Description

Slot Status

Act

Unlocked

Disabled

Module is in Active state (not Standby)

Module administrative state is Unlocked

Module operational state is Disabled

System Status

Alert A

Alert B

Alert C

Not used

Not used

Not used

Telco Status

Minor

Major

Critical

CPX minor alarm

CPX major alarm

CPX critical alarm

Table 2–2. Remote Alarm Connector

Pin

Signal

1

Critical Alarm

2

Critical Alarm Return

3

Major Alarm

4

Major Alarm Return

5

Minor Alarm

6

Minor Alarm Return

7

Rack Alarm (not used)

8

Rack Alarm Return (not used)
