Table B–1. Connection Requirements and Physical Layer
Specifications
Connections
Cables, Connectors, and Specifications
ATM packet network
(OC-3 fiber optic cables)
Physical interface:
Short-haul, SMF or MMF, OC-3
fiber optic cable
ATM module is a 155-Mbps
SONET bridge between the cPCI
bus in the CPX-1000, and the
external ATM network.
Xmt power:
Multi-mode
−19 to −14 dBm (nominal)
Single mode
−15 to −8 dBm (nominal)
Rcv power:
Multi-mode
−44.5 dBm to −8 dBm
Single mode
−34 dBm to −8 dBm
Wave length:
1310 nm (typical)
Framing type:
C-bit parity
Logical interface:
UNI
Max. span length:
SMF 5000m; MMF 550m
ATM packet network
(DS-3 coaxial cables)
Physical interface:
DS-3 short-haul coaxial cable
ATM module is a 44.736 Mbps full
duplex link between the cPCI bus
in the CPX-1000 and the external
ATM network.
Impedance: 75
Ω (nominal)
Max. span length:
450 ft. of 734A or equivalent
coaxial cable
Termination:
Dual socket BNC coaxial
connectors
Signal amplitude:
±1.75 volts ±10%
Xmt power:
-4.7 to +3.6 dBm
Transmission rate:
44.736 Mbps full duplex
Framing type:
C-bit parity
Logical interface:
UNI
Line coding:
B8ZS
