Siemens IK PI · 2004 6/83
AS-Interface Slaves
I/O modules for operation in IP20 control cabinet
SlimLine
6
■
Technical specifications (continued)
4 inputs/4 outputs 4 inputs/4 outputs 4 inputs/4 outputs
Screw-type connection Spring-loaded connection Spring-loaded connection
Standard slave Standard slave Standard slave
2- and 3-wire 2- and 3-wire 2- and 3-wire
Relay PNP transistor (1 A) PNP transistor (2 A)
3RK1 402-3CE00-0AA2 3RK1 400-1CG00-0AA2 3RK1 400-1CG01-0AA2
Total current input in mA £ 270 £ 270 £ 270
Inputs
• Sensor supply via AS-Interface Short-circuit and overload
withstand capability Short-circuit and overload
withstand capability Short-circuit and overload
withstand capability
• Voltage range in V 20 to 30 20 to 30 20 to 30
• Current carrying capacity
for sensor supply in mA
200 200 200
• Connection of sensors 2- and 3-wire system 2- and 3-wire system 2- and 3-wire system
• Switching level High in V ³ 10 ³ 10 ³ 10
• Input current Low/High in mA £ 1.5 / ³ 5 £ 1.5 / ³ 5 £ 1.5 / ³ 5
Outputs
• Type of output Relay Electronics Electronics
• Current carrying capacity
per output in A DC 12 / DC 13 typ.
-- 1 2
• Maximum summation current
per module in A
-- 4 4
• Short-circuit protection External back-up fuse 6 A gL/gG Built-in No (internal
fusible link)
• Inductive interference protection
(free-wheeling diode)
Not applicable -- --
• Polarity reversal protection -- Built-in Built-in
• External 24 V DC supply voltage Not applicable Terminal 13 = L24+
Terminal 19 = M24 Terminal 13 = L24+
Terminal 19 = M24
• I
th
5 -- --
• AC-15 3 -- --
• DC 13 24 V 1 -- --
• DC 13 110 V 0.2 -- --
• DC 13 230 V 0.1 -- --
• Watchdog Built-in Built-in Built-in
I/O configuration 7 7 7
ID/ID2 code 0/F 0/F 0/F
Assignment of data bits
• Data bit D0 IN1/OUT1 IN1/OUT1 IN1/OUT1
• Data bit D1 IN2/OUT2 IN2/OUT2 IN2/OUT2
• Data bit D2 IN3/OUT3 IN3/OUT3 IN3/OUT3
• Data bit D3 IN4/OUT4 IN4/OUT4 IN4/OUT4
Connection Via screw terminal Spring-loaded terminal connection Spring-loaded terminal connection
Conductor cross-sections in mm
2
-- Solid: 2 ´ (0.25–1.5)
Finely stranded with end sleeve:
2
´ (0.25–1)
Finely stranded without end sleeve:
2
´ (0.25–1.5)
AWG conductor connections solid
or stranded: AWG 2
´ (24–16)
Solid: 2 ´ (0.25–1.5)
Finely stranded with end sleeve:
2
´ (0.25–1)
Finely stranded without end sleeve:
2
´ (0.25–1.5)
AWG conductor connections solid
or stranded: AWG 2
´ (24–16)
Note -- Disassembly tool for spring-
loaded terminal connection:
See "Accessories" Disassembly tool for spring-
loaded terminal connection:
See "Accessories"
