Siemens IK PI · 2004 6/12
AS-Interface
AS-Interface safe compact modules
AS-Interface Safety at work
6
■
Technical specifications (continued)
Outputs
• Type of output -- Electronics Electronics
• Current carrying capacity
DC 12/13 in A
-- 2 --
• Current carrying capacity typ.
(max. 4 A per module) in A
-- Max. 0.18 Max. 4
• Pin assignment outputs -- 3 = "–"
4 = Output
5 = Earth connection 3 = "–"
4 = Output
5 = Earth connection
• Short-circuit protection -- Built-in Built-in
• Inductive interference protec-
tion (free-wheeling diode)
-- None Built-in
• External voltage supply
24 V DC
-- -- Via black AS-Interface flat cable
• Watchdog -- Built-in Built-in
I/O configuration 0 7 7
ID/ID2 code B B B
Assignment of data bits
• Socket 3 and 4 Not assigned (closed) Not assigned (closed) Not assigned (closed)
• Socket 5 Not assigned (closed) Pin 4 = OUT1 (D0)
Pin 2 = Not assigned (closed) Pin 4 = OUT1 (D0)
Pin 2 = Not assigned (closed)
• Socket 6 Not assigned (closed) Pin 4 = OUT2 (D1)
Pin 2 = Not assigned (closed) Pin 4 = OUT2 (D1)
Pin 2 = Not assigned (closed)
• Socket 7 and 8 Not assigned (closed) Not assigned (closed) Not assigned (closed)
AS-Interface certificate Yes Yes Yes
Approvals UL, CSA UL, CSA UL, CSA
Degree of protection IP67 IP67 IP67
Earth connection -- PIN 5 of each M 12 socket is
connected to the grounding plate in
the mounting plate via a pin
(outputs only sockets 5 and 6). PIN 5 of each M 12 socket is
connected to the grounding plate in
the mounting plate via a pin
(outputs only sockets 5 and 6).
Ambient temperature in °C -25 to +85 -25 to +85 -25 to +85
Storage temperature in °C -40 to +85 -40 to +85 -40 to +85
Number of I/O sockets 2 4 4
Status indication
• I/O display Yellow LED Yellow LED Yellow LED
• U
Aux
-- -- Green LED
• AS-Interface/diagnostics
display
Green/red LED Green/red LED Green/red LED
Connection via mounting plate for K45 compact
module via mounting plate for K60 compact
module via mounting plate for K60 compact
module
Addressing Front addressing socket,
after the 15th addressing,
the module keeps the last address Front addressing socket,
after the 15th addressing,
the module keeps the last address Front addressing socket,
after the 15th addressing,
the module keeps the last address
