AS-Interface Slaves
SlimLine
I/O modules for operation in IP20 control cabinet
6
■
Technical specifications (continued)
SlimLine S45
4 inputs/4 outputs
4 inputs/4 outputs
4 inputs/4 outputs
Screw-type connection
Screw-type connection
Screw-type connection
Standard slave
Standard slave
Standard slave
2- and 3-wire
2- and 3-wire
2- and 3-wire (floating)
PNP transistor (1 A)
PNP transistor (2 A)
PNP transistor (1 A) floating
3RK1 400-1CE00-0AA2
3RK1 400-1CE01-0AA2
3RK1 402-3CE01-0AA2
Total current input in mA
£ 270
£ 270
£ 40
Inputs
• Sensor supply via AS-Interface
Short-circuit and overload
withstand capability
Short-circuit and overload
withstand capability
Short-circuit and overload
withstand capability
• Voltage range in V
20 to 30
20 to 30
20 to 30
• Current carrying capacity
for sensor supply in mA
200
200
200
• Connection of sensors
2- and 3-wire system
2- and 3-wire system
2- and 3-wire system
• Switching level High in V
³ 10
³ 10
³ 10
• Input current Low/High in mA
£ 1.5 / ³ 5
£ 1.5 / ³ 5
£ 1.5 / ³ 5
Outputs
• Type of output
Electronics
Electronics
Electronics
• Current carrying capacity
per output in A DC 12 / DC 13 typ.
1
2
1
• Maximum summation current
per module in A
4
4
4
• Short-circuit protection
Built-in
Built-in
Built-in
• Inductive interference protection
(free-wheeling diode)
Built-in
Built-in
Built-in
• Polarity reversal protection
Built-in
Built-in
Built-in
• External 24 V DC supply voltage
Terminal 13 = L24+
Terminal 19 = M24
Terminal 13 = L24+
Terminal 19 = M24
Sensor supply:
Terminal 13 = U_s+
Terminal 19 = U_s–
Actuator supply:
Terminal 14 = L+
Terminals 20 to 24 = M
• I
th
--
--
--
• AC-15
--
--
--
• DC 13 24 V
--
--
--
• DC 13 110 V
--
--
--
• DC 13 230 V
--
--
--
• Watchdog
Built-in
Built-in
Built-in
I/O configuration
7
7
7
ID/ID2 code
0/F
0/F
0/F
Assignment of data bits
• Data bit D0
IN1/OUT1
IN1/OUT1
IN1/OUT1
• Data bit D1
IN2/OUT2
IN2/OUT2
IN2/OUT2
• Data bit D2
IN3/OUT3
IN3/OUT3
IN3/OUT3
• Data bit D3
IN4/OUT4
IN4/OUT4
IN4/OUT4
Connection
Via screw terminal
Via screw terminal
Via screw terminal
Note
--
--
The module has four floating inputs
and four floating switching outputs.
For the input and output circuits, an
external additional supply of 20 to
30 V according to VDE 0106 (PELV)
Safety Class III is required.
