Console Commands Silex Page 89
Part Number 140-00192-100
Command Description
19 00080000 GPIO Trigger4: GPIO4 0 to 1
20 00100000 GPIO Trigger5: GPIO5 0 to 1
21 00200000 GPIO Trigger6: GPIO6 0 to 1
22 00400000 GPIO Trigger7: GPIO7 0 to 1
23 00800000 GPIO Trigger8: GPIO8 0 to 1
24 01000000 GPIO Trigger9: GPIO1 0 to 1
25 02000000 GPIO Trigger10: GPIO2 1 to 0
26 04000000 GPIO Trigger11: GPIO3 1 to 0
27 08000000 GPIO Trigger12: GPIO4 1 to 0
28 10000000 GPIO Trigger13: GPIO5 1 to 0
29 20000000 GPIO Trigger14: GPIO6 1 to 0
30 40000000 GPIO Trigger15: GPIO7 1 to 0
31 80000000 GPIO Trigger16: GPIO8 1 to 0
*Not implemented in early releases of SX-560 firmware.
Power Configuration Commands
Table 41 Power Configuration
Command Description
SET POWER LEVEL n Sets the power save mode. High power is for fastest throughput,
low power is for lowest power consumption.
SET POWER
Where is a numeric value as follows
0 = High Power (processor always on, never sleeps)
2 = Low Power
This is the time in milliseconds to wait before the processor goes
into power save mode. If no I/O occurs on the network or from the
attached peripheral within this time period, the processor will go
into low power mode. The value must be between 0 and 18000000
(30 minutes). A value of 0 disables processor power saving. The
default value is 0.
SH POWER Shows the current power control mode.
