Page 10 silex Installing the Evaluation Daughtercard
Part Number 140-00192-100
Table 4 OEM Interface Signal Descriptions
Signal Pin Type Description
GPIO_0, GPIO_1,
GPIO_2, GPIO_3,
GPIO_4, GPIO_5,
GPIO_6l GPIO_7,
GPIO_8, GPIO_9,
GPIO_10 2, 3, 4, 7, 8,
9, 10, 11,
12, 13, 15 Input/Output General Purpose Input/Output Signals 0-
10, User defined (GPIO_10 is normally
used for the Test Button and GPIO8-
GPIO10 are normally used for the status
LEDs)
RXD0 22 Input Serial Port 1 Receive Data
TXD0 14 Output Serial Port 1 Transmit Data
RTS0- 20 Output Serial Port 1 Request To Send
CTS0 16 Input Serial Port 1 Clear to Send
RXD1 34 Input Serial Port 2 Receive Data
TXD1 26 Output Serial Port 2 Transmit Data
RTS1- 32 Output Serial Port 2 Request To Send
CTS1 28 Input Serial Port 2 Clear to Send
USB+, USB- 19, 21 Input/Output USB V1.1 Host Interface
SPI_CS 25 Output Serial Peripheral Interface Chip Select
(high-true)
SPI_MOSI 31 Output Serial Peripheral Interface Data Out
SPI_MISO 33 Input Serial Peripheral Interface Data In
SPI_CLK- 27 Input and (low-
true) Serial Peripheral Interface Clock
IIC_SCL 37 Input/Output Inter-IC Bus (IIC) Clock
IIC_SDA 39 Input/Output Inter-IC Bus (IIC) Data
RESET- 24 Output Open-Drain with Pull-up on SX-560
+3.3VDC 6. 23. 30, 35 Power Power VCC Input
GND 5, 24, 29, 36 Power Power Ground
Electrical Characteristics
The power requirements, port pinouts, GPIO characteristics, cable connections and wireless operational
modes are described below.
Power Input
Power to the SX-560 Module and the SX-560-6900 Evaluation Daughtercard is supplied through the
power jack, located at J6, at +5VDC ±10%. Use the included power supply or an equivalent +5VDC
power supply with a minimum of 1 amp capacity.
Power of +3.3VDC ±5% is supplied to the SX-560 Module via the I/O header, JP13.
