Installing the Evaluation Daughtercard Silex Page 17
Part Number 140-00192-100
LCD Interface
A 16x2 LCD display is available as an option for the SX-560-6900 Evaluation Daughtercard. This LCD
can be controlled from either Serial Port 2 or via the SPI interface. The LCD display plugs into header
JP1. Header JP12 is used to select serial or SPI control (place a jumper on pins 1 and 2 to select serial,
or place the jumper on pins 2 and 3 to select SPI).
OEM Interface Electrical Characteristics
Table 12 OEM Signal Parameter Descriptions
Parameter Symbol Condition Minimum Maximum Unit
Input high voltage Vih 2.0! Volts
Input low voltage Vil 0.8 Volts
Output high voltage
UART0_TXD, UART0_RTS,
UART1_TXD, UART1_RTS
UART2_TXD
Voh Ioh = 4mA 2.4 Volts
Output low voltage
UART0_TXD, UART0_RTS,
UART1_TXD, UART1_RTS
UART2_TXD
Vol Iol = 8mA 0.4 Volts
Output high voltage
GPIO 1 to 10, SPI, CS, SPI_SDO,
SPI_CLK, Reset_N
Voh Ioh = 8mA 2.4 Volts
Output low voltage
GPIO 1 to 10, SPI, CS, SPI_SDO,
SPI_CLK, Reset_N
Vol Iol = 8mA 0.4 Volts
Input Leakage Current Ii 0 < Vin < 3.3v -10 +10 µA
