Advanced Configuration Silex Page 59
Part Number 140-00192-100
GPIO set message format This message may be optionally sent by the
remote computer when an E-GPIO connection is
active. This message allows the remote
computer to set the state for any GPIO pins
configured as outputs. This is equivalent to the
SET GPIO DATA command.
The message is in the format:
GPIO=00ab
Where ab are 2 hex digits representing the state
of the GPIO pins. Since there are only 8 GPIO
pins on the SX-560, the first two digits should
always be 0. Any other message sent to the E-
GPIO connection is ignored. If the message is
formatted incorrectly, it is ignored.
Example:
Local> set gpio mon en
Local> set gpio addr 192.168.1.100
Local> set gpio port 9999
Local> set gpio poll 100
Local> sh gpio mon
E-GPIO mode Enabled
E-Cable destination 192.168.1.100
Poll interval 100 milliseconds
Not connected
Table 26 GPIO SNMP Management
The GPIO pins can also be managed via SNMP. The available MIB items are described in this section.
The GPIO related MIB items are in the Silex private MIB, and the GPIO tree is at
gpio=enterprises.1240.2.3.4.9.
GPIO bit mask
Integer
read-only gpio.1
This is an integer representing a bit mask indicating what GPIO pins are available. There is a 1 for
each GPIO pin that is present. For the SX-560, this value is 255 (xFF), indicating 8 GPIO pins.
