Installing the Evaluation Daughtercard Silex Page 5
Part Number140-00192-100
Chapter 2
Installing the Evaluation Daughtercard
The SX-560-6900 Evaluation Daughtercard is designed to help you in the development of the necessary
hardware and software required to use the SX-560 module. It includes I/O connectors, cables, and power
supply in an easy-to-use package. The SX-560 Module is installed in the Evaluation Daughtercard as
shown in Figure 2.
Figure 2 Installing SX-560 Module in Evaluation Daughtercard
